3 VOL KNOB ABS (SILVER SPRAY) Bonso 2 For Vol & Ch
VOL KNOB ABS (BLACK COLOR) 2
4 SQ KNOB ABS (SILVER SPRAY) Bonso 4 For Sq, Rf, Mic gian, Q up/down
SQ KNOB ABS (BLACK COLOR) 4
5 ILLUMINATOR(VOL) ACRYL, CLEAR Bonso 1 1 For Vol
6 ILLUMINATOR(CH) ACRYL, CLEAR Bonso 1 1 For Ch
7 ILLUMINATOR(SQ) ACRYL, CLEAR Bonso 4 4 For Sq, Rf, Mic gian, Q up/down
8 ILLUMINATOR(PA) ACRYL, CLEAR Bonso 1 1 For Pa/off/dx
9 KEY PAD 6 SILICONE, Hs=60, PU Coating ECO 050328-06 Hankyung 1 1 -
10 KEY PAD 2 SILICONE, Hs=60, PU Coating ECO 050328-06 Hankyung 1 1 -
11 RING NUT BsBm, Ni plating Hankyung 6 6 For Vol
12 SCREW MACH(+) M2.6*5L, NATURAL, FH Bonso 4 4 Escutcheon + Main body mounting
13 Vol illuminator sticker wood free paper, 58*7*
ECO 050328-02 Bonso 1 1 For Vol
14 Sq illuminator sticker wood free paper, 46*7*0 ECO 050328-02 Bonso 5 5 For Sq illuminator & Ch illuminator
* UPPER COVER ASS'Y
15 UPPER COVER SPC+BLACK coating Hankyung 1 1 -
16 FELT(COVER) 8*146*0.3t, BLACK Hankyung 2 2 For upper cover adhesive(location: side)
17 CUSHION 20*24*4.0t, EVA SPONGE, BLACK Hankyung 1 1 For upper cover adhesive(location: center)
18 SCREW Mach(+) M3*8L-TAPTITE, BLACK, B ECO 050103-01 Bonso 5 5 Upper cover + Main body mounting
* BOTTOM COVER ASS'Y
19 BOTTOM COVER SPC+BLACK coating Hankyung 1 1 -
20 BRACKET(SPK) SPC, 1.6t Hankyung 3 3 For speaker
21 FELT(SPK) Φ76*0.2t, BLACK Hankyung 1 1 For speaker
22 FELT(COVER) 8*146*0.3t, BLACK Hankyung 2 2 For bottom cover adhesive(location: side)
23 SCREW Mach(+) M3*8L-TAPTITE, BLACK, B ECO 050319-01 same as item.18 Bonso 3 3 Bracket(spk) mounting
24 SCREW Mach(+) M3*8L-TAPTITE, BLACK, B ECO 050103-01 same as item.18 Bonso 1 1
Bottom cover + Main body mounting(location: back)
* FRONT PCB ASS'Y
25 REFLECTOR(HOLDER) ACRYL Bonso 1 1 For diffuser
26 DIFFUSER ACRYL, 45.8*19.3*2.4t Bonso 1 1 For diffuser
27 LCD HOUSING SPTE, 0.3t Hankyung 1 1 For diffuser
28 WHITE SHEET Hankyung 1 1 For diffuser
29 ZEBRA 30*9.2*2.0t, CARBON SILICONE Hankyung 1 1 For diffuser
30 FELT(S/W) Φ4.5*Φ17*0.3t, BLACK ECO 050103-01 Hankyung 3 3 -
31 SCREW Mach(+) M2.6*8L-TAPTITE, Ni platin
ECO 050103-01 Bonso 2 2 Front Pcb mounting
* MAIN PCB ASS'Y
32 MAIN BODY EGI, 1.0t Hankyung 1 1 -
33 HEAT SINK AL, 2.0t Hankyung 1 1 -
34 TX SHIELD CAN(1) SPTE, 0.3t Hankyung 1 1 For Main PCB(location: lower)
35 TX SHIELD CAN(2) SPTE, 0.3t Hankyung 1 1 For Main PCB(location: upper)
36 VCO SHIELD CAN SPTE, 0.3t Hankyung 1 1 For Vco
37 SHIELD COVER SPTE, 0.3t ECO 050302-02 Hankyung 1 1 For TX shield can(2)
38 BUSH NYLON66+GRASS 15% Hankyung 1 1 For TR
39 ANT. TERMINAL SPTE, 0.2t Hankyung 1 1 For Antenna
40 MICA MICA, 0.6t Hankyung 1 1 For TR
41 SCREW Mach(+) 3*8L-TAPTITE, Black, BH ECO 050103-01 same as item.18 Bonso 4 4 Main PCB + Main body mounting
42 SCREW MACH(+) M3*10L, Black, BH ECO 050412-02 Bonso 3 3 TR mounting
43 SPRING WASHER M3 Bonso 3 3 TR mounting
44 NUT M3, SS41 Bonso 3 3 TR mounting
45 CORD STOPPER PP Hankyung 1 1 Wire stopper
46 Cu Tape-1 Cu 63.6*9*0.1t ECO 050328-02 Bonso 1 1 For TX shield can(1)
47 Cu Tape-2 Cu 77*15*0.1t ECO 050328-02 Bonso 1 1 For TX shield can(1)
