3. MC Box Fuel Management Operation
MCBOXElectronicPanelsaredesignedfortheprivatedistributionoffuel(orotherliquids).
AllofthemodelsintheseriesarecharacterisedbythesameformforwhichtheMCBOXis
known:asolidmetalstructure,high-accuracymeasurementsinthedispensedproductandPC
softwarethatisdesignedforsimplicity.
Thiselectronicpanelallowsyoutocontrolandmonitorprivateusefuelconsumptionviaafuel
dispenserwithpumpandowmeter.
TheMCsystemconsistsofamulti-userpanel,dedicatedsoftwareandtheoptiontoconnecttoa
PC
The MC BOX System has the ability to:
•Switchthepumpon;
•Recogniseauthorisedusers;
•Presetthedispensequantity;
•Managethepulsemeter;
•Manageanexternallevelswitchthatturnso󰀨thepumpintheeventofminimumowlevel;
•Operateanexternalnozzleswitch;
•ConnectdirectlytoaPC;
•Connecttoanexternalprinter
Thepaneliseasytoinstallandisadequatelyprotected.Thewiringconnectionscanbeeasily
accessed.Thegroupcanalsobesuppliedwithameter,tobeinstalledtogetherwiththepump.
Specications
Panelwithdualdisplay,keyboardandi-buttonreader.
Theelectricboxcanbeopened,allowingeasyaccesstothewiring.
Maximumpowersupply:6.5amps.
Optional
•PCSoftwarewithdedicatedRSconverterori-buttonreadertoexportdata.
•I-buttonkeysforusers.
•High-accuracyovalgearowmeters.
Performance
•80or120-usercapacity(dependingonmodel),managedviapasswordori-buttonkey.
•Totalconsumptioncalculationfordenedperiodsforeachuser.
•Localmemorythatcanstoredatauntilthelast255dispenses.
•Vehicleidenticationandmileagetrackingoption.
•Dispensingdateandtimecontrol.
•Dedicatedsoftwarethatallowsyoutoprintdispensedataforeachuser.
•Abilitytomanageupto16controlpanelswithonesinglesoftware.
•KeyreaderwithUSBplugforexportingdata.
•RSconverterwithUSBplugfordirectconnectiontothePCviacable(upto1000m)
MC Box Installation
General
TheMCBOXcanbeinstalledoutdoors.Nevertheless,itisadvisabletolocateitundertheshelter
ofarooftoensurethedispenser’slongevityandprovidegreatercomfortduringrefuelinginthe
eventofbadweather.Theinstallationofthedispensermustbecarriedoutbyskilledpersonnel
andperformedaccordingtotheinstructionsprovidedinthischapter.
Electrical connections
Thepowerconnectionsmustbeworkmanlikeperformedbyskilledpersonnel,instrictcompliance
withthelawsapplicableinthecountryofinstallationandwiththeinstructionsonthewiring
diagramsinthismanual.
