TuffStuff CHL-610WS - Page 23

23
14
76
23
75
74
31
Step 13 Assembly List
Item Qty. Description
23 1 LAT CABLE
31 1 SNAP LINK Z/P 8MM X 80MM
74 1 7/8 RD X 1 5/8 LINK 3/16 CABLE
75 1 CABLE STOPPER SHELL 1 1/2 X 1 3/4
76 1 OVAL HEAD SCREW Z/P #10-32 X 1 1/8
14 1 FLOATING DOUBLE PULLEY BRACKET LT
Note:
Some parts have been removed for Clarity.
Step 13 Lat Cable Assembly
Note:
Continue on Next Page.
23CHL-610WS High/Low Pulley w/200 Lbs Weight Stack for CSM-600
