MFT-2700 Multi-Funtional Trainer
Assembly List
Item # Description Qty.
3 SUPPORT HOUSING 2
9 LEFT SIDE PIVOT ARM SWIVEL HOUSING 1
13 RIGHT SIDE PIVOT ARM SWIVEL HOUSING 1
21 ALUMINUM PULLEY 3/8 X 1 X 2 2
22 ALUMINUM PULLEY 3/8 X 1 X 3 1/2 2
34 BUTTON HEAD SOCKET CAP SCREW GR-8 Z/P 3/8-16 X 1 3/4 4
45 FLAT WASHER SAE Z/P 3/8” 12
74 NYLON INSERT JAM LOCK NUT GR-8 Z/P 3/8-16 4
81 RETAINING SNAP RING EXT. PLAIN .925 X 1 X .042 2
89 SPLIT LOCK WASHER Z/P 3/8” 4
96 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 4
15
