TuffStuff RLP-200 - Component Identification; Comprehensive Parts List

REV0
ITEM DESCRIPTION REV PART NO. QTY ITEM DESCRIPTION PART NO. QTY
1 ADJUSTABLE CHROME TUBE 0 UP3938 1
37 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 1 BNH0842 2
2 ADJUSTABLE FOOT PLATE 0 UP3939 1
38 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 2 3/4 BNH2065 2
3 ADJUSTMENT TUBE HOUSING 0 UP3940 1
39 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 3 BNH0331 4
4 BASE FRAME 0 UP3941 1
40 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 5 1/2 BNH2066 1
5 CARRIAGE 0 UP3942 1
41 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 5 5/16 BNH2048 2
6 CARRIAGE HANDLE 0 UP3943 2
42 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 6 1/4 BNH2067 2
7 HACK SQUAT FOOT PLATE 0 UP3944 1
43 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 1/4 BNH2038 14
8 HANDLE STOPPER LEFT SIDE 0 UP2229 1
44 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 1/2 BNH2044 2
9 HANDLE STOPPER RIGHT SIDE 0 UP2228 1
45 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/4 BNH2045 6
10 HEAD SUPPORT PAD 0 UP3945 1
46 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 BNH2046 4
11 LEFT SIDE FRAME RAIL 0 UP3946 1
47 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 5 BNH2051 2
12 LINEAR SHAFT 1 3/16 X 59 1/2 0 UP3947 2
48 HEX HEAD CAP SCREW GR-5 Z/P 5/16-18 X 3/4 BNH2049 1
13 LOWER BACK PAD 0 UP3948 1
49 HEX HEAD CAP SCREW GR-5 Z/P 5/16-18 X 5 1/2 BNH2069 2
14 PAD BRACKET 0 UP0087 4
50 HEX HEAD CAP SCREW GR-5 Z/P 5/16-18 X 5/8 BNH2068 16
15 REAR FRAME 0 UP3949 1
51 HEX KEY 3/32" BNH0373 1
16 RIGHT SIDE FRAME RAIL 0 UP3950 1
52 HEX KEY 7/32" BNH0575 1
17 SEAT PAD 0 UP3951 1
53 LITHIUM GREASE SMALL CONTAINER BNH0705 1
18 SHOULDER PAD LT SIDE 0 UP3952 1
54 METAL HINGE BNH0046 2
19 SHOULDER PAD RT SIDE 0 UP3953 1
55 NYLON INSERT JAM LOCK NUT Z/P 1/2-13 BNH2027 11
20 SPACER 7/8 0 UP3954 2
56 NYLON INSERT JAM LOCK NUT Z/P 3/8-16 BNH2026 14
21 UPPER BACK PAD 0 UP3955 1
57 PLASTIC HORIZONTAL ELLIPTICAL SHOE BNH1847 2
22 WEIGHT HOLDER 0 UP3956 1
58 PLASTIC INSERT CAP 2 X 3 _ 11-14 GA BNH0052 2
23 WEIGHT HOLDER SUPPORT 0 UP3957 1
59 PLASTIC INSERT CAP 2" SQ BNH0012 6
24 ALUMINUM CAP 1.020" RD BNH0537 4 60 PLASTIC INSERT CAP ELLIPTICAL 2 X 4 BNH1794 2
25 ALUMINUM PILLOW BLOCK BEARING BNH2072 4 61 PLASTIC INSERT CAP FOR 1 13/64" HOLE DIA BNH1317 2
26 BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8 BNH0528 4 62 PLASTIC INSERT ELLIPTICAL GUIDE (2X4) BNH1760 1
27 CHROME CAP 1 7/8" RD. BNH1016 2 63 PULL PIN 1/2 X 3 1/2 (YELLOW) BNH0603 2
28 DECAL-CAUTION 1 3/4 X 5 1/2 BNH0126 1 64 RUBBER DONUT 1 X 2 1/2 BNH0062 2
29 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2 BNH0142 2 65 RUBBER GRIP 1 ID X .125 X 5 1/2 BNH0958 2
30 DECAL-FOR BEST PERFORMANCE 1-1/4 X 1-1/2 BNH0143 3 66 RUBBER GRIP 1 ID X .125 X 8 BNH0966 2
31 DECAL-WARNING KEEP HANDS AND FINGERS.. BNH0620 2 67 RUBBER WASHER 1 7/8 ID X 3 OD X 9/16 TK BNH1311 2
32 FLAT HEAD SOCKET CAP SCREW 3/8-16 X 1 1/4 BNH0667 2 68 SOCKET SET SCREW ALLOY 10-32 X 1/8 BNH0473 10
33 FLAT PHILLIPS SCREW ZINC # 2 X 1/2 BNH1480 2 69 SPACER 1/2 IDX 3/4 OD X 1 3/4 L BNH2073 2
34 FLAT WASHER SAE Z/P 1/2" BNH2031 18 70 SPLIT LOCK WASHER Z/P 5/16" BNH2070 18
35 FLAT WASHER SAE Z/P 3/8" BNH2030 42 71 TUFFSTUFF LOGO ALUMINUM SMALL BNH1323 1
36 FLAT WASHER USS Z/P 5/16" BNH2071 18 72 URETHANE BUMPER 1 3/4" BNH0229 2
RLP-200
Parts List
COLOR CHART
BOLD FONT = SUB-ASSEMBLY PARTS
BLACK= HARDWARE
8 RLP-200 Leg Press / Hack Squat
