TuffStuff SPT-6X - Page 12

STEP 3
E
F
G
STEP 4
I
G
H
8
51
79
86
81
92
49
59
21
85
59
49
5
4
8
51
79
86
81
92
49
59
21
85
59
49
5
4
STEP 5
M
L
K
J
I
5
4
5
4
STEP 2
E
B
A
D
C
59
49
59
21
85
49
92
81
86
51
79
8
59
49
59
21
85
49
92
81
86
51
79
8
STARTING POINT
STEP 1
RUN CABLE THROUGH STARTING POINT INTO
TOP SWIVEL PULLEY BRACKET AS SHOWN AND
THEN ASSEMBLE IT TO THE UNIT.
FOLLOW LETTER SEQUENCE
TO ROUTE THE CABLE.
Assembly List
Item # Description Qty.
4 DOUBLE FLOATING PULLEY BRACKET LT 1
5 DOUBLE FLOATING PULLEY BRACKET RT 1
8 LAT CABLE 1
21 TOP BEARING HOUSING 2
45 Oval Head Phillips Screw #10-32 X 1 1/8 2
49 FLAT WASHER SAE B/O 3/8” 4
51 Cable Stopper Shell 1 1/2 x 1 3/4 2
59 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4 4
81 SNAP LINK Z/P 8MM X 80MM 2
85 SPLIT LOCK WASHER B/O 3/8” 4
86 7/8 Rd X 1 5/8 Link 1/8 Cable 2
92 CONTOUR ERGO HANDLE SHORT STRAP 2
NOTE: PULLEY BRACKETS (#4, #5) HAVE BEEN
SWAPED PLACES FROM PREVIOUS OWNERS
MANUAL. ASSEMBLE AS SHOWN ABOVE.
12 SPT-6X Six-Pak Trainer
www.tuffstuffitness.com
Step 8 (Lat Cable Routing)
92
81
86
51
45
45
51
86
81
92
