TuffStuff SPT-6X - Loosely Tighten Loosely Tighten

43
84
47
47
43
1
11
75
75
20
9
75
20
75
9
Assembly List
Item # Description Qty.
1 ADJUSTABLE DOUBLE PULLEY BRACKET 1
9 LONG DOUBLE SWIVEL PULLEY BRKT 2
20 SHORT DOUBLE SWIVEL PULLEY BRKT 2
43 FINISHED HEX NUT B/O 1/2-13 2
47 FLAT WASHER SAE B/O 1/2” 2
75 RETAINING SNAP RING EXT. PLAIN 1 1/4” 4
84 SPLIT LOCK WASHER B/O 1/2” 1
Loosely Tighten
70%
Loosely Tighten
70%
Loosely tighten all hardware in this step.
DO NOT Fully Tighten. Some component(s)
may need pre-assembly and or alignment
during the assembly process.
7SPT-6X Six-Pak Trainer
www.tuffstuffitness.com
Step 3
