Tuft & Needle Adjustable Frame - Connecting the Bars (Right Side Rail)

28
REMOVE STRAPPING TAPE AND PROTECTIVE MATERIAL
1. Lift the first Crossbar (D) and place one end
of it into a slot on the Side Rail (Right) (A).
Ensure the Thread on the Side Rail (the metal
part facing upwards) passes through the hole
at the end of the Crossbar.
2. Place a Crossbar Knob (E) onto the thread
connecting the Side Rail and the Crossbar.
Turn the Knob counter-clockwise until it is
hand tight.
3. Repeat steps 1 and 2 with the second Crossbar
for Side Rail (Right) (A).
Connecting the Bars
3
A
D
x2
E
CAUTION
Risk of minor or moderate injury through crushing
The Side Rails are not secured while they are standing alone. If they
fall over, this may lead to minor or moderate injury through crushing.
• Do not attempt to stand the Side Rails upright before they are
connected to the Crossbars
• Be careful not to knock over the Side Rails
• Ensure that you are wearing suitable footwear while assembling
the Bed Frame
