Tuft & Needle Adjustable Frame - Connecting the Bars (Left Side Rail)

29
1. Connect the Crossbars (D) to the Side Rail
(Left) (B) as shown in the Step 3.
Connecting the Bars
4
CAUTION
Risk of minor or moderate injury through crushing
Gripping the Side Rails‘ moving parts may lead to minor or
moderate injury through crushing.
• Do not touch moving parts when lifting or moving the
Side Rails. Only grip the fixed parts
CAUTION
Risk of minor or moderate injury through crushing
While screwing in the Crossbar Knobs, you will need to lift the
moving parts of the Side Rails. Allowing these parts to fall may
lead to minor or moderate injury through crushing.
• Ensure moving parts do not fall down during assembly
D
D
B
