7 Start up
7.1 Filling the device
Figures 5 - 7
Prepare the spaying media separately according to the manufacturer’s instructions and
do not mix in the container. The following table provides information about dosing
quantities:
NOTE!
First add half of the water, then the media, followed by the other half of the water.
Check that the drain aperture E is closed before filling.
- Remove the container cap A and fill the device through the filling sieve B. Close the
container with the container cap.
CAUTION
Note maximum fill level (see technical data), safety instructions and permissible work-
ing materials.
Check fill quantity.
Comply with the data of the spray product manufacturer!
Fasten the spray lance K in the spray lance seat C.
7.2 Correctly connecting and fitting the shoulder strap to the body
Figure 8
Your device is equipped with two padded shoulder straps which can be adjusted in length.
The device must be worn as close to the body as possible and parallel to the spine for opti-
mal load distribution and fatigue-free operation.
Fasten the shoulder straps as shown to the lower left and right outer strap buttons and
position the device on your back.
Tighten the carrying straps over the shoulders by pulling the lower strap ends. The car-
rying straps can be lengthened or shortened by adjusting the strap buckles.
Water Concentration
0,1% 0,15% 0,2% 0,25% 0,3% 0,5% 1,0% 1,5%
1 liter 1 ml 1,5 ml 2 ml 2,5 ml 3 ml 5 ml 10 ml 15 ml
2 liters 2 ml 3 ml 4 ml 5 ml 6 ml 10 ml 20 ml 30 ml
3 liters 3 ml 4,5 ml 6 ml 7,5 ml 9 ml 15 ml 30 ml 45 ml
4 liters 4 ml 6 ml 8 ml 10 ml 12 ml 20 ml 40 ml 60 ml
5 liters 5 ml 7,5 ml 10 ml 12,5 ml 15 ml 25 ml 50 ml 75 ml
10 liters 10 ml 15 ml 20 ml 25 ml 30 ml 50 ml 100 ml 150 ml
