Tunturi E30 - Page 74

7474
E-30
1 Main frame 1
2 Front stabilizer 1
3 Rear stabilizer 1
4 End cap for front stabilizer 2
5 End cap for rear stabilizer 2
6 Carriage bolt M8*60 4
7 Curved washer Ø8 8
8 Domed nut M8 4
9 Allen screw M8*16 4
10 Normal knob 1
11 Left pedal 1
12 Right pedal 1
13 Seat post 1
14 Flat washer Ø17*Ø8 1
15 Carriage bolt M8*40 1
16 Nylon nut M8 2
17 Seat 1
18 Computer 1
19 Cover for seat post 1
20 Lower computer wire 1
21 Motor wire 1
22 Hand pulse wire 2
23 Grommet 1
24 Handlebar 1
25 Clamp 1
26 Allen screw M8*20 2
27 Cover for clamp 1
28 T-type knob 1
29 Screw M5*12 4
30 Motor 1
31 Front post 1
32 Upper computer wire 1
33 Crank 1
34 Seat post bushing 1
35 Washer 2
36 Axle for flywheel 1
37 Flywheel 1
38 Flange Nut 2
39 L/R Chain Cover L/R 1/1
40 Self-tapping screw ST5*15 8
41 Self-tapping screw ST5 8
42 Belt pulley 1
43 BB Assembly 1
44 Magnetic assembly 1
45 Plastic spacer 2
46 Bearing 6900 1
47 Hex head bolt M8*55 1
48 Belt 1
49 Sensor Bracket 1
50 Hex head Bolt M6*25 1
51 Hex Head Nut M6 2
52 Spring 1
53 Idler wheel assy 1
54 Powder spacer 1
55 Spring for magnetic assy 1
56 Hex head nut 1
57 Adjusting bolt 1
58 Cover for Crank 2
# Description Spec Qty # Description Spec Qty
