Tunturi F40 - Page 25

83
F-40
70 Bearing 6003RS 1
71 Bearing 6203RS 1
72 Bearing 6300RS 1
73 Flat washer 1
74 Star washer Ø10xØ17x1t 2
75 Bushing 1
76 Bushing 1
77 Servomotor set 1
78 Magnetic brake set 1
79 Flat washer 2
80 Hex screw M6x16L 2
81 Spring washer 2
82 Idler 1
83 Idler wheel 1
84 Nut M8 1
85 Flat washer Ø8.5xØ25x1t 1
86 Hex screw M8x18L 1
87 Wave washer Ø10.5xØ15x0.3t 2
88 Flat washer ØxØ12x1t 1
89 Hex screw M6x12L 1
90 Idler spring 1
91 Screw M8x69L 4
92 Flat washer 4
94 Handlebar knob 1
96 Handlebar fixed cover 1
97 Front foot 1
98 Adjusting cushion 2
99 Foot cap 2
100 Screw 3/16’x11/8’ 4
101 Transportation wheel 2
102 Nut M8 2
103 Screw M8x40L 2
104 Flate washer 2
105 Rear foot 1
106 Adjusting cushion 2
107 Screw 3/16’x11/8’ 4
108 Foot cap 2
109 Handlebar clamp 1
110 Screw M7x30L 1
111 Spring washer 1
112 Flat washer 1
