Important: Read the
installation instruction section
before connecting the device.
Important: Higher pressures may
damage the device. Do not
connect the obstruction measuring
pipes to the compressed air circuit.
Electric Specifications
Electric Power
• 115 Vac ± 10% 50-60 Hz – 25W
• 230 Vac ± 10% 50-60 Hz – 25W
• 24 Vac ± 10% 50-60 Hz – 25W (optional)
• 24 Vdc ± 10% 25W (optional)
Selectable Output Voltage
• 24 Vdc
• 24 Vac
• 115 Vac
• 230 Vac
Inputs And Outputs Not Galvanically Insulated
• Enable contact (remote cleaning enable).
• Fan contact (post-cleaning).
• 4 – 20mA (dP remote reading).
The solenoid valves connected to the unit are normally closed.
The activation of a solenoid valves causes them to open and consequently let out a jet of
air.
Alarm Relay
The two alarm relays contain 2 clean contacts on terminals 4-5 and 6-7.
Maximum permitted load: 3A @ 250 Vac - 2A @ 24 Vdc, Vac.
The relays are normally closed, opens in case of alarm, and opens to the control unit off in
the absence of power.
Fuses:
1 x 1 A @ 230 Vac.
1 x 1 A @ 115 Vac.
1 x 3 A @ 24 Vac (optional).
1 x 3 A @ 24 Vdc (optional).
Working Temperature
from -10°C to 55°C
Storage Temperature
-20°C to 60°C
T
imer Specifications
Pulse time (valve opening)
from 50 ms to 5 sec
Pause time (interval between valve openings)
1 sec - 999 sec
Differential Pressure Gauge:
Measurable pressure range: from 0 to 4 kPa
Maximum applicable pressure: 16 kPa - 0.16 bar
