List Of Functions
F01:
Configuring the operation mode.
Possible values: 0 – Manual (dP excluded)
1 – Automatic (dP included) Default
2 – Automatic with forced cycle (dP included)
3 – Proportional (dP included)
By setting the Manual Mode, it is necessary change the value of F11 Fan Recognition on 0,
detection by contact and not by dP, close together the contacts to 12.13 on J2 terminal block.
F02:
Solenoid activation time.
Possible values: 0.05” – 5.00” step 0.01”.
Default = 0.20”.
F03:
Washing pause time between solenoid valves.
Possible values: 001” – 999” step 1”.
Default = 020”.
F04:
Number of connected outputs.
Possible values: 01 – 16 step 1.
Default = 001.
F05:
Output voltage setting, must agree with jumpers.
Possible values: d24, a24, 115, 230.
Default = a24.
F06:
Manual output activation.
Possible values: 1 – number of outputs set in F04.
Press SET to activate the set output.
F07:
Zero dP threshold.
Possible values: 0.00 kPa – 3.99 kPa step 0.01.
Default = 0.00 kPa.
F08:
Cleaning cycle start threshold high dP set point.
Possible values: 0.00 kPa – 3.99 kPa step 0.01.
Default = 0.80 kPa.
F09:
Cleaning cycle stop threshold low dP set point.
Possible values: 0.00 kPa – 3.99 kPa step 0.01.
Default = 0.40 kPa.
F10:
Max dP Alarm Threshold (Filter Clogging if detected for longer than 20 seconds)
Possible values: 0.00 kPa – 3.99 kPa step 0.01.
Default = 3.00 kPa.
F11:
Fan on recognition mode for after cycle cleaning.
Possible values: 0 from contact – 1 from dP.
Default = 1 from dP.
Set to 0 if F01 is 0, Manual Mode dP excluded.
F12:
dP threshold for fan on recognition if F11=1.
Possible values: 0.00 kPa – 3.99 kPa step 0.01.
Default = 0.10 kPa.
