Electri
cal Compa
rtment and
Contro
ls
6-7
(See Figures 4-1a/b)
Item #
Part Number
Description
Used on Model(s)
19
C0299
Convection Motor Assy
All
20
103170
Circuit Breakers CB2 & CB3
15 Amp
C3Multi &
C3/CM
ulti
21
101285
K7 Solid State Relay
C3Multi &
C3/CM
ulti
22
102070
Thermostat, Magnetron (21
2F)
All
23
102085
Thermostat, EC Box
All
NS
100542
EMI Filters (not shown
)
C3Multi & C3/CMulti
NS
T0286
EMI Filter
C3/AB & C3/C
38
40
Table of Contents
Default Chapter
3
Table of Contents
3
Read this First
5
Important Safety Instructions
6
Precautions to Avoid Possible Exposure to Excessive Microwave Energy
7
Precautions to be Observed before and During Servicing to Avoid Possible Exposure to Excessive Microwave Energy
8
Grounding Instructions
9
Power Cord Replacement
9
RF Interference Considerations
10
Chapter 1 Installation Specs
11
Oven Description
12
Installation
12
Oven Location
13
Basic Cleaning Procedures
16
Chapter 2 Cleaning & Care
17
Chapter 3 Theory of Operation
17
Theory of Operation Description
19
Glossary of Common Operating Terms
19
Chapter 4 Fault Codes
23
Fault Code Introduction
24
Chapter 5 Test
27
Passwords for Operating C3 Ovens
32
Chapter 6 Electrical Compartment & Controls
34
Electrical Component Locations C3/C Multi
34
Electrical Component Parts Lists
38
Control Panel Detail
40
Control System Troubleshooting
41
Chapter 7 Cook Door
45
Door Switch Adjustment
46
Door Removal and Replacement
52
Chapter 7 Cook Door
53
Chapter 8 Convection Circuit
64
Catalytic Converter
66
Convection Element and Thermocouples
67
How to Turn Heaters on & off
67
Changing Heater Operating Voltage
67
Heater Circuit Defective Messages
68
Convection (Blower) Motor Operation
73
How to Turn Blower on
73
Checking Input Voltage at Motor Controller
73
Blower Circuit Defective Messages
74
Blower Motor Controller Fault Codes & Troubleshooting
75
Delta Blower Motor Controller Fault Codes & Trobleshooting
77
Convection Motor Parts List
80
Chapter 9 Microwave Circuit
83
Measuring for Microwave Radiation Leakage
84
Microwave Circuit Defective Messages
85
Magnetron High Voltage Power Supply
88
Magnetron Testing
91
Magnetron Removal and Replacement
91
Component Testing (Diode, Capacitor, Transformer)
93
Transformer Specifications
93
Waveguide Components Parts List
98
Chapter 10 (SMT)I/O BOARD & Schematics
99
