TurboChef C3/AB User Manual

TurboChef Technologies, Inc. C Series
6-6
ELECTRICAL COMPONENTS PARTS LIST SUMMARY
Item # Part
Number
Description Used on Model(s)
1
T0322
Circuit Breaker CB1
-
35A w/Trip Coil
C3/AB & C3/C
2
100596
12 Amp Aux Fuse
All
2b
100597
25 Amp Heater Fuse
C3/C
2c
100591
Fuse Holders
All
3
R7603
Convection High Limit
C3/AB & C3/C
3
102016
Convection High Limit
C3Multi & C3/CMulti
4 M9608 24 VDC Power Supply All
6 T0278 &
T0309
Relay (24 VDC Coil/240 VAC Output) &
Socket
All
7
101285
Solid State Relay for Heater
All
8
101285
Solid Sate Relay for Magnetron
All
9
T0265
SMT Controller
All
10 M9609 Electrical Compartment Cooling Fan C3/AB & C3Multi
10 100519 EBM Electrical Compartment Cooling Fan C3/C & C3/CMulti
11 T0262 Magnetron Cooling Fan All
12
101891
Stirrer Motor
All
13
100480
HV Diode
All
14 100206 HV, Capacitor, 2500 V All
15
102091
Filament Transformer
All
16
102093
Mag
netron Transformer T1
All
17 100860 Magnetron All
18
100441
Blower Motor Speed Controller
All
ELECTRICAL COMPONENTS PARTS LIST (CON’T): All C Series Ovens-
