turbofan EC40D10 Installation And Maintenance Manual

5
240064-1
2 • TECHNICAL DATA
TABLE 1: GENERAL DATA - ELECTRIC OVENS
Model Supply Voltage Frequency Total Input Amps
EC40M5
EC40D5
220-240 Vac, 1P+N+E
380-415 Vac, 3P+N+E
50Hz 7,25kW
32
11
220-240 Vac, 1P+N+E
380-415 Vac, 3P+N+E
60Hz 7,25kW
32
11
EC40M7
EC40D7
380-415 Vac, 3P+N+E 50Hz 12,5kW 18
380-415Vac, 3P+N+E 60Hz 12,5kW 18
EC40M10
EC40D10
380-415 Vac, 3P+N+E 50Hz 14,5kW 22
380-415Vac, 3P+N+E 60Hz 14,5kW 22
Warning: The safety device (RCD to be  tted on the power line to the appliance)
must be sized for a leakage of 1 mA x kW of power installed.
( * ) Flexible cable underneath sheath resistant to oil with designation 60245-IEC-57
TABLE 2: GENERAL WATER DATA
Model
Water
pressure
kPa (psi)
Softened
water
consumption
max. l/h
Water
connection
EC40M5
EC40D5
200 - 500
(30 - 72)
8 1 x R 3/4
(1)
EC40M7
EC40D7
200 - 500
(30 - 72)
16 1 x R 3/4
(1)
EC40M10
EC40D10
200 - 500
(30 - 72)
16 1 x R 3/4
(1)
(1)
Ovens with cleaning kit are fitted with two water inlets, one for non-softened cold water and the other for hot water (max. 50°C) or cold
softened water.
Model
Net Weight Kg.
Model
Net Weight Kg.
EC40M5 74 EC40D5 74
EC40M7 90 EC40D7 90
EC40M10 104 EC40D10 104
TABLE 3: GENERAL DATA - NET WEIGHT
Hardness: between 60 and 90 ppm
PH: greater then 7.5
Chlorides less than 30 ppm
