TA-880 user manual
Page 35
3. Position the second cabinet directly underneath the first. Fit a
BS-780 biscuit into the top
kelping braket of the lower cabinet to keep the backs of the boxes and act as the hinge. Lower
the top cabinet and feed the swords into the sword boxes. Make sure that the biscuit engages
into the bottom kelping bracket slot of the upper cabinet. The lower end of the swords will be
visible through the handle boxes of the lower cabinet.
4. Secure them with safety linch-pins on both sides of the cabinet.
Repeat this procedure with any further cabinets required to complete the column of speakers.
