user manual
TA-880
TA-880 user manual
Page 36
Flying swords are provided with two holes ast each end. This allows for a choice of four
incremental vertical angles depending on which hole the linch-pin is located in, and which
will determine the combined vertical coverage of the column.
11°
B
A
8°
A
A
15°
B
B
Sword hole position Inter-cabinet angle
A – A 8º
A – B 11º
B – B 15º
