Turbosound MANCHESTER Series Quick Start Guide

6 Manchester Series MAN210-FG/MS121/MV210-HC Quick Start Guide 7
Connections
Mode BackPanel and Front Panel Connector InternalSchematic
MV210-HC
MS121 rear panel
MS121 front panel
BI-AMP, Input Low +
BI-AMP, Input Low -
BI-AMP, Input High +
BI-AMP, Input High -
1-
2-
2+
1+
Amplier Channel 1
Amplier Channel 2
LF 2
MHF
1+
+
-
+
-
+
-
1-
2+
2-
1+
1-
2+
2-
LF 1
NL4
Input/
Link
NL4
Input/
Link
1-
2-
2+
1+
Input SUB -
Input SUB +
Pins 2+/2- do not connect to the LF driver, they are just
used to link.
LF 1
NL4
Input/
Link
1+
1-
2+
2 -
+
-
1+
1-
2+
2 -
1+
1-
2+
2 -
nc
nc
NL4
Input/
Link
NL4
Front
Input
1-
2-
2+
1+
Front Input SUB +
Not Connected
Not Connected
Front Input SUB -
Rigging and Acoustic SimulationSoftware
Refer to the MAN210-FG rigging manual for safe suspension and installation of the loudspeakers, y grid and all suspensionhardware.
MANCHESTER Series loudspeakers and y grid are designed and tested to strict BGV-C1 standards. Suspension of these speakers must be performed in accordance
with the MAN210-FG y grid rigging manual available online at turbosound.com
EASE Focus 3 is an acoustic simulation program, available as a free download from https://www.afmg.eu/en/ease-focus
