user manual
TCS Compact series
tcs compact manual
page 25
70/100V Line Distributed Systems
Line transformer models are supplied with step-down transformers with voltage taps at
P, P/2, and P/4 watts, where P is the maximum power rating of the line transformer, and
these are accessed via the 4-way barrier strip only.
70v/100v Line
COMMON
P/4
P/2
P
