Turbosound TCS COMPACT SERIES User Manual

user manual
TCS Compact series
tcs compact manual
page 36
2-Way Enclosures
Model TCS-151C TCS-121C TCS-101C TCS-081C
Dimensions
HxWxD
652x468x423mm
25.7”x18.4”x16.7”
553x407x352mm
21.8”x16”x13.9”
508x366x319mm
20”x14.4”x12.5”
415x308x270mm
16.3”x12.1”x10.6”
Net Weight
25.5kg (56.1lbs) 19kg (41.8lbs) 16.5kg (36.3lbs) 12kg (26.4lbs)
LF driver
1 x 15” (381mm) 1 x 12” (305mm) 1 x 10” (254mm) 1 x 8” (203mm)
HF compression
driver
1 x 1” (25mm)
Frequency Response
±4dB
45Hz - 20kHz 60Hz - 20kHz 65Hz - 20kHz 70Hz - 20kHz
Nominal Dispersion
70°H x 40°V @ -6dB points 100°H x 60°V @ -6dB points
Power Handling
Recommended
amplifier power @ 8
Ohms
300 watts r.m.s.
600 watts program
600 watts
250 watts r.m.s.
500 watts program
500 watts
200 watts r.m.s.
400 watts program
400 watts
Sensitivity
1 watt @ 1 metre
99dB 97dB 95dB 93dB
Maximum SPL
continuous->
peak->
124dB
130dB
122dB
128dB
119dB
125dB
116dB
122dB
Internal Crossover
1.8kHz 2.2kHz 3kHz
High Pass
24dB/octave 12dB/octave
Low Pass
12d/B octave low-pass
Nominal Impedance
8 ohms
Construction
15mm (5/8”) birch plywood enclosure 12mm (1/2”)
Grille
Powder coated perforated steel mesh, backed with black reticulated foam on black
cabinets; backed with white acoustically transparent cloth on white cabinets
Connectors
(1) Neutrik Speakon NL4MP, wired pin1+: positive, pin 1-: negative, pins 2+ and 2- N/C
(1) 4-way barrier strip connector
Finishes
Black semi-matt textured paint (standard), white, raw wood and custom colours
IP54 Weather
Resistant Version
TCS-151CW TCS-121CW TCS-101CW TCS-081CW
Notes:
TCS-101C has a rotatable Converging Elliptical Waveguide™ for use with swivel bracket.
TCS-081C has a fixed Converging Elliptical Waveguide™
