page 7
TCS-101C
The TCS-101C is a compact passive two-way loudspeaker enclosure. It consists of a 10”
reflex-loaded low frequency driver and a 1” high frequency compression driver on a
rotatable 100°H x 60°V Converging Elliptical Waveguide™ in an optimally tuned
trapezoidal cabinet constructed from 15mm (5/8”) birch plywood.
M8 rigging points are provided on the back panel to enable fixed installation use with
optional Turbosound WB-20 wall and CB-55 ceiling brackets. M6 rigging points are
provided for use with OmniMount™ 60 series brackets. The SB-101 swivel bracket can be
used to mount the cabinet horizontally to walls or ceilings with a wide range of
downward angle.
