Figure 1. Flying Bar Assembly
Figure 2. Exploded Parts List
Lifting Point Safety Point
Tilting Strap Point
Flying Chain Suspension Point
To suspend four columns of Flashlight
enclosures with indexed horizontal adjustment.
FC-780 FLYING CHAINS
one pair required
for each enclosure
to be flown.
TS-780 TILTING STRAP
one required
for each column
of enclosures.
(These are handed
left & right, the
left ones have RED
Shortening Hooks,
the right ones BLUE
Shortening Hooks).
FB-780A MAIN BAR
