user manual
TMS series
TMS series user manual
Page 10
Technical Specifications
TMS-High TMS-Low
Dimensions
(H x W x D)
480mm x 452mm x 419mm
(18.9” x 17.8” x 16.5”)
835mm x 576mm x 576mm
(32.9” x 22.7” x 22.7”)
Net weight 21.5kg (47.3lbs) 40.5kg (89.1lbs)
Frequency range 200Hz – 20kHz ±3dB 43Hz – 200Hz ±3dB
Dispersion 80°H x 40°V @ -6dB points N/A
Sensitivity 101dB, 1 watt @ 1 metre 101db, 1 watt @ 1 metre
Power handling 200 watts r.m.s., 400 watts program 500 watts r.m.s., 1000 watts program
Recommended amplifier
power
400 watts / ch @ 8 ohms 1000 watts / ch @ 8 ohms
Impedance 8 ohms 8 ohms
Max SPL (cont/max) 124dB/130dB 128dB/134dB
Construction 15mm (5/8”) plywood, finished in black
textured paint. Two recessed carrying handles.
Integral pole mount socket. Powder coated
galvanised perforated steel mesh grille.
15mm (5/8”) plywood, finished in black textured
paint. Two recessed carrying handles. Integral
pole mount socket. Four heavy duty wheels.
Connectors 2 x Speakon NL4 2 x Speakon NL4
Rigging options 9 x M10 threaded internal rigging points N/A
Spare Parts
Stock Code Model Description
LS1028 LS-1028 10” (254mm) mid frequency driver
05B1086 RC-1028 Recone kit
LS1817 LS-1817 18” (457mm) low frequency driver
05B5166 RC-1817 Recone kit
04A9335 CD-121 HF compression driver
05B9325 RD-121 Replacement HF diaphragm
07A806 T6 castor set of 4 Castor set for TMS Low
