3 MODULE INTERFACES
2 Change History
Serial Number Update Date Updated Content
Version after
Update
1 3/21/2020 This is the first
release.
V1.0.0
3 Module Interfaces
3.1 Dimensions and Footprint
WBR3L has two rows of pins with a 2 mm pin spacing. Each row has 8 pins. The
WBR3L dimensions are 16±0.35 mm (W)×24±0.35 mm (L) ×2.9±0.15 mm (H). The
dimensions of WBR3L are as follows:
3 / 25
