8 Multi Format LCD Monitor
3. Controls & Functions
LVM-170A : FRONT
● [USB]
- Updates new rmware and color calibration.
● [ANALOG] Button/Lamp
- Used to select desired Analog input.
- Press the button to activate the analog
input menu-selection, then use UP
and DOWN button to select desired input.
* Please refer to “7. Button Functions [1]
ANALOG Button” for more information.
● [DIGITAL] Button/Lamp
- Used to select desired Digital input. (HDMI,
DVI Digital)
- Press the Digital Button to activate the
Digital input menu-selection, then use the
Knob to select desired input.
*
Please refer to “7. Button Functions [2]
DIGITAL” for more information.
● [SDI-A] Button/Lamp
- Used to select SDI-A input.
● [SDI-B] Button/Lamp
- Used to select SDI-B input.
● [F1 ~ F5] Button/Lamp
- Performs the function that the user set as
hot-keys.
- The selectable the hot-key menu comes up
when you hold the keys. You can select the
hot-key functions from it.
● [SCAN] Button/Lamp
- Used to change the scan mode.
*
Please refer to “8. Other Functions [1]SCAN”
for more information.
● [ASPECT] Button/Lamp
- Used to change the display ratio between
4:3 and 16:9.
- Activates in the order of [16:9]-[4:3]-[2.35:1]-
[1.85:1]-[15:9]-[16:10] -[AUTO]-[16:9].
To Next Page
