Multi Format LCD Monitor 9
3. Controls & Functions
LVM-170A : FRONT
● [MARKER] Button/Lamp
- Used to activate/deactivate the Marker.
- The Marker is normally displayed when you
select Aspect ratio you want in OSD Menu.
● [H/V DELAY] Button/Lamp
- Used to check horizontal sync. and vertical
sync. simultaneously.
● [BLUE ONLY/MONO] Button/Lamp
- Press the button to remove red and green
from the input signal and display the screen
only under a blue signal. Press the button
again to activate mono mode.
- This function is not activated in the RGB, DVI
ANALOG, DVI DIGITAL, HDMI modes.
● [INFO.] Button
- Displays the current function and setting of
the monitor.
● [MENU/EXIT] Button/Lamp
- Activates OSD menu.
● [ENTER/UP/DOWN] Knob
- Used to con rm a chosen value.
- Used to move the cursor in OSD menu.
● [POWER] Button/Lamp
- Turns on or o the monitor power.
● [OPERATE] Lamp
- Indicates the status of power connection and
monitor operation.
- The LED is o with power o .
- The LED is red when the monitor is in waiting
mode with power on.
- The LED is green when the monitor is
operating.
● [AUDIO OUT] (Phone jack)
- Outputs dis-embedded audio signal, HDMI
audio signal or stereo signal from outside
through internal speaker or phone jack.
● [TALLY] Lamp
- Tally lamp that can be toggled in green or
red using the REMOTE(RJ-45) port.
To Next Page
