10
LVM-171W / 241W / 401W / 461W / 571W
· CVBS1/Y/G/S-Y (BNC)
Signal input terminal used to feed monitor COMPOSITE 1, S-VIDEO Y, COMPONENT
Y, RGB G signals.
· CVSBS2/Pb/B (BNC)
Signal input terminal used to feed monitor COMPOSITE 2, RGB B, COMPONENT Pb signals.
· CVSBS3/Pr/R/S-C (BNC)
Signal input terminal used to feed monitor COMPOSITE 3, S-VIDEO C, COMPONENT
Pr, RGB R signals.
· SDI-IN A (BNC)
SDI/HD-SDI signal input terminal that provides A signal.
· SDI-OUT A (BNC)
SDI/HD-SDI signal output terminal used for SDI A output.
· SDI-IN B (BNC)
SDI/HD-SDI signal input terminal that provides B signal.
· SDI-OUT B (BNC)
SDI/HD-SDI signal output terminal used for SDI B output.
· Audio in & out
Built in Audio Disembedder and Internal Speakers Stereo Audio out using phone jack.
External Audio in for Stereo Speaker out
· ~ AC IN
Used to supply AC power; 100V~240V input range.
· DC 12V/24V IN
Used to supply DC power 12V(LVM-171W) or 24V(LVM-241W).
Information
Input VIDEO connection method
Connector Composite Component S-Video
1CVBS1YG Y
2
CVBS2 Pb B
No Con.
3CVBS3PrRC
To Next Page
