21
LVM-171W / 241W / 401W / 461W / 571W
· WAVEFORM POSITION
This item sets the waveform position.(R-B,C-B,L-B,L-T,C-T,R-T)
· WAVEFORM SIZE
This item sets the waveform size.( Large,Medium,Small)
· TIME CODE ENABLE
This item displays the time code. (VITC, LTC)
Other Functions
[1] ANALOG Mode Usage
This product is capable of processing numerous input signals in ANALOG mode.
The ANALOG input settings are as follows:
1. Press ANALOG button on the front of the product and activate the menu below.
2. Highlight the value you desire by using the UP/DOWN button and press the MENU
button to confirm your selection. From this point the OSD menu operates identically
to the MENU operations discussed above.
Warning!!
When using ANALOG mode, always check the input method and modify the setting as
needed for optimized output results.
!
