41
08 PRODUCT SPECIFICATIONS
LVM-181S
LCD
Size 18.5"
Resolution 1920 x 1080 (16:9)
Pixel Pitch 213(per one triad) x 213 [um]
Support Color 16.7M colors (True 8 Bit)
Luminance of white 500cd/m2 (Typical)
Contrast Ratio 1000 (Typical)
Active Area 408.96(H) x 230.04 (V) [mm]
Input Connector
2 X BNC SDI A/B Channel Input
3 X BNC Analog Input
1 X HDMI HDMI Input
1 X DVI-I DVI-I(RGB) IN
Output
2 X BNC SDI A/B Channel (Loop Through Out)
3 X BNC Analog Output
Input Signal
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
Analog CVBS / Component / RGB
DVI-Analog 640x480/720x400/800x600/1024x768/1366x768
DVI-D (PC mode) 640x480/800x600/1024x768/1366x768
DVI-D (HDMI mode) 1080i(60) / 720i(60) / 480i(60) / 480p(50)
HDMI 480i(60) / 480p(60) / 576i(50) / 576p(50) / 720p(60) / 1080i(60) / 1080p(60)
Analog Input Spec
CVBS 1.0Vpp (with Sync)
Component 1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
RGB 1.0Vpp (G With Sync), 0.7Vpp (B,R)
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p (60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i (60/59.94/50)
SMPTE-274M 1080i (60/59.94/50), 1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
2K Format 2048 x 1080(23.98p/psf, 24p/psf)
Audio
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack), Internal Speaker(Stereo)
Power AC100~240V(50~60Hz) / DC 12V
Power Consumption (Approx.) 30 Watts
Operating Temperature 0℃ to 40℃ (32℉ to 104℉)
Storage Temperature -20℃ to 60℃ (-4℉ to 140℉)
Dimensions
Main Body (mm/inch) 442.5 x 309 x 70 (mm) / 17.42 x 12.17 x 2.76 (inch)
With stand (mm/inch) 489.7 x 332.8 x 137.5 (mm) / 19.28 x 13.1 x 5.41 (inch)
Weight 7Kg / 15.43 lbs
Accessory
Basic AC Power Cord, Stand, USB Cover, Control Knob Cap
Optional Sun Hood, Acrylic Filter, Rack Mount Kit, Carrying Case, V-Mount, G-Mount
*The specifications above may be changed without notice.
Multi Format LCD Monitor
