44 Multi Format LCD Monitor
<Focus Assist ON>
<Focus Assist ON>
<Range Error OFF>
<Range Error ON>
[7] FOCUS ASSIST
[8] RANGE ERROR
● Focus Assist function assigns a color to
the pixels in the shape or boundary area
of the image to inform the user to make
the best focus.
- With this function, user can easily
dierenciate the focused area from
out-focused area especially shooting
with shallow depth of eld.
- Available types are [Mono] and [Color] types.
*
[Mono] : Background image is mono type.
*
[Color] : Background image is original color
type.
● Pixels with Y’ or C’ levels exceeding the
designated levels of Y MAX, Y MIN, C MAX
and C MIN shall blink.
- Analyzes the input signal’s Luma(Y’) and
chroma information(C’) and if the
input signal exceeds the designated
minimum value and maximum value,
the pixel shall blink. This function is to
help the user to easily nd out any unwanted
level of signals and for better exposure
setting.
8. Other Functions
