TVLogic R-5T User Manual

LCD Rack Mountable Monitor 10
5. Menu Operations
• BRIGHTNESS
- Used to set the brightness(=oset) level from
-100 to 100.
• CONTRAST
- Used to set the contrast(gain) level from -100
to 100.
• CHROMA
- Used to set the saturation level from -50 to 50.
• SHARPNESS
- Used to set the Sharpness level from 0 to 24.
• PEAKING BOOST
- Used to set the Peaking Boost level from 0 to 24.
• 3DLUT LOAD
- Used to apply the internally stored 3DLUT.
- Maximum 3 x 3DLUT les can be stored.
- The le name can be set up to 20 characters
including the extension.
• 3DLUT SYNC
- Used to load a list of available 3DLUT les
currently stored in the FLASH MEMORY.
- Available 3DLUT formats are Cube/GV Lut/
Quantel/Davinci/AssScratch.
- Available sizes of the 3DLUT are 17 or 33.
• 3DLUT IMPORT 1/2/3
- Used to save the 3DLUT stored in the external
memory to the internal memory 1/2/3 area.
- Once saved, the 3DLUT can be maintained
even when the power is turned ON/OFF.
- The le name can be set up to 20 characters
including the extension.
[1] PICTURE
PICTURE 같이 R-5T
DEFAULT
SYNCHRONIZATION
NONE 1
NONE 1
NONE 1
BRIGHT
CONTRAST
CHROMA
SHARPNESS
PEAKING BOOST
3D LUT LOAD
3DLUT SYNC
3DLUT IMPORT 1
3DLUT IMPORT 2
3DLUT IMPORT 3
+90
+90
+90
+ 1 2
+12
