TVLogic R-5T User Manual

LCD Rack Mountable Monitor 40
10. Product Specifications
*
The specication above may be changed without notice.
*
When using a DC Adapter other than the one supplied by the manufacturer, please be advised that
the adapter with DC 12V/3A ~ 6A can be compatible with the monitor.
R-5T
LCD
Size 5.5”
Resolution 1920×1080(16:9)
Pixel Pitch 0.0213(W) x 0.0639(H) mm
Color Depth 16.7M (True)
Viewing Angle H : 160 degrees / V : 160 degrees
Luminance of white
500 cd/ m
2
(Center)
Contrast Ratio 1,000 : 1
Display Area 122.7(H)x69.0(V) mm
Input
1 X HDMI HDMI Input
1 X BNC SDI Input (12G-SDI x 1 / 3G-SDI x 1)
2 X BNC 3SDI Output (12G-SDI x 1 / 3G-SDI x 1), HDMI to SDI conversion output
Input Signal
12G-SDI 11.88G bps
6G-SDI 5.94Gbps
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
HDMI
1080p(60/59.94/50/30/25/24/23.98)/1080i(60/59.94/50)/720p(60/50)/480i(60)
/480p(60)/576i(50)/576p(50)
SDI Input Signal
Formats
SMPTE-ST 2082 3840x2160(60/50/59.94p)
SMPTE-ST-2081 3840x2160(30/29.97/25/24/23.98p)
SMPTE-425M-A/B 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Power DC 12V 2.5A
Power Consumption (Approx.) 35W
Tally Signal In/Out Level DC5V ±2V
Operating Temperature
0℃ to 45℃ (32
℉
to 113
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 439 X 87.5 X 118.7 (17.28 X 3.44 X 4.67)
Main Body Dimensions with RMK (mm/inch) 480.2 X 87.5 X 141.7 (18.9 X 3.44 X 5.58)
Box Dimensions (mm/inch) 555 X 180 X 250 (21.85 X 7.08 X 9.84)
Weight 2.9Kg/6.4lbs
Basic Accessories DC Power adapter, Rack Mountable Kit
Optional Accessories -
