• FOCUS ASSIST
- Focus Assist helps the shooters to easily nd
out the exact area in the picture with good
focus, simply by adding colors on the shape
or boundaries of the object in the picture.
- Activates in order of [Mono On]-[Color On]-
[O]
*
[Color On] : Only the boudary of the area
with good focus is displayed with the
designated color.
*
[Mono On] : The boundary of the area with
good focus is colored with the designated
color, while the rest of the areas(pixels) have
only Y’(Luma) signals to be black & white
image.
*
See section “7. Other Functions [6] Focus
Assist” for more information.
• FOCUS AS COLOR
- Used to select a color for Focus Assist among
red, green and blue.
- This feature is available only when the Focus
Assist mode is activated.
• FOCUS AS LEVEL
- Used to set the edge dierence value between
the edges in an image.
- Available values are from 0 to 100. Larger the
value the more sophisticated the detail
detection.
- Designated color is displayed when the difference
of the edges exceeds the previously set value.
- This feature is available only when the FOCUS
ASSIST mode is activated.
• DSLR
- Select the DSLR camera to be used with the
monitor. Available mode is [CANON 7D].
* DSLR cameras’ screen size and aspect ratio
of Live / Record / Playback modes vary
depending to their manufacturer.
• DSLR SCALE
- This is a special function for CANON/NIKON DSLR
cameras.
- Used to scale the image with dierent
resolution as to the operation mode(Live View/
Record/ PlayBack) of the camera to fullll the
screen.
*
See section “7. Other Functions [8] DSLR
SCALE” for more information.
• TIMECODE
- Used to set the Time Code.
- Available modes are [O], [VITC], and [LTC].
[4] DISPLAY / VIDEO
5. Menu Operations
DISPLAY / VIDEO이 R-5T
DSLR
DSLR SCALE
TIMECODE
FOCUS ASSIST
FOCUS AS COLOR
FOCUS AS LEVEL
ARRI CAM STATUS
LD INFO
INDEX LETTER
CANON 7D
LIVE VIEW
OFF
OFF
RED
OFF
OFF
OFF
+ 90
PAGE(2/2)
To Next Page
