TVLogic R-5T User Manual

LCD Rack Mountable Monitor 38
VIDEO Support Resolution
9. Video Support Resolution
Input Signal
Interfaces
Signal Foramt (SD SDI)
SD SDI
single link
720x487(59.94i)
720x576 (50i)
YCbCr 4:2:2 10bit
Input Signal
Interfaces
Signal Format (HD SDI)
HD-SDI
single link
1920x720 (50/59.94/60P)
YCbCr 4:2:2 10bit
1920x1080
(23.98/24/25/29.97/30p)
(50/59.94/60i)
(24/25/29.97/30psf)
Input Signal
Interfaces
Signal Format (3G SDI)
3G-SDI (A/B)
single link
1920x1080 (60p/59.94p/50p) YCbCr 4:2:2 10bit
1920x1080
(30/29.97/25/24/23.98p)
(30sF/29.97sF/25sF/24sF/23.98sF)
(60/59.94/50i)
YCbCr 4:2:2 12bit
RGB 4:4:4 10bit / 12bit
YCbCr 4:4:4 10bit / 12bit
1280x720 (50/59.94/60P)
RGB 4:4:4 10bit
YCbCr 4:4:4 10bit
