TVLogic S-32P User Manual

05 MENU OPERATIONS
19
Studio Wall Monitor
[3] COLOR
• COLOR TEMP. (Color Temperature)
- Controls the color temperature and allows
instant access to preset the color temperature
settings.
- Available options are [3200K], [5000K], [5600K],
[6500K], [9300K], [CUSTOM 1], [CUSTOM 2],
[CUSTOM 3].
- [R/G/B Gain], [R/G/B Bias] and [COLOR COPY]
menus activate only in the [CUSTOM] mode.
- Backlight value is adjustable for each color
temperature.
• GAIN RED / GREEN / BLUE
- Used to set Red/Green/Blue Gain(or Picture,
Contrast) level.
- Available range is -256 to 255.
- These menus are activated in CUSTOME 1/2/3
modes only.
• BIAS RED / GREEN / BLUE
- Used to set Red/Green/Blue Bias (or Oset.
Mainly aects on Black level).
- Available range is [-100] to [100].
- These menus are activated in CUSTOM 1/2/3
modes only.
• COLOR COPY
- Used to copy the R/G/B Gain value of pre-stored
color temperature settings.
- In User mode, nd and select the color
temperature to be used with the Knob and
press the knob button to copy and apply the
Gain value to [GAIN RED], [GAIN GREEN],
[GAIN BLUE].
- This menu is activated in CUSTOM 1/2/3 modes
only.
• COLOR SPACE
- Used to select the color output format.
- This menu is activated only when [STANDARD]
is set to [HD].
- Available options are [BT.709], [SMPTE-C], [EBU],
[D-CINEMA], [BT.2020], and [NATIVE].
• GAMMA
- Used to change the Gamma Curve between
[1.0] and [3.0] with 0.05 increment.
- This menu is activated only when [STANDARD]
is set to [HD].
• BACK LIGHT
- Adjusts the current value of the backlight of the
LCD panel.
- Available values are from [0] to [100].
COLOR Temp.
Color
2/2
GAIN RED
GAIN GREEN
GAIN BLUE
BIAS RED
BIAS GREEN
BIAS BLUE
COLOR SPACE
COLOR COPY
GAMMA
BACK LIGHT
S-46P
6500K
NORMAL
3200K
2.4
0
0
0
0
0
0
0
