03 CONTROLS & FUNCTIONS
7
Studio Wall Monitor
S-32P / S-42P / S-46P / S-55P ALL PART (FRONT / REAR)
POWER
INDECATE LED
IR SENSOR
USB
AUDIO
IN/OUT
REMOTE RS-422
IN/OUT
AC IN SDI-B
IN/OUT
SDI-A
IN/OUT
DVI-I HDMI SFP-B SFP-AENTER DOWN UP MENU
