RP 3200 STAR User’s Manual
17
9. Specifications
♣Important!
When connecting or disconnecting the power supply from the printer, be sure that the following
cautions are observed.
Use a power supply (Limited Power Supply) of DC 24V±10% and more than 2.5A.
Be careful about installing the printer in an area where there is noise.
Take appropriate measure to protect against electrostatic AC line noise, etc.
9-1. General Specifications
(1) Printing Method Direct line thermal printing.
(2) Print speed 200mm/sec.
(3) Dot density
180 DPI (Hor / Ver)
180 / 180 (0.142mm / 0.142mm dot)
(4) Printing Width
180 DPI
Max 72mm (512 dots)
(5) Number of print columns.
No. of columns
Font “A”
Font “B”
180 DPI
42
56
(6) Roll paper Refer to chapter 2 for details on the recommended roll Paper.
Paper width : 50mm~82.5mm
Roll diameter : Max. Ø80mm
(7) Weight 1.7Kg
