RP 3200 STAR User’s Manual
5
2-2. Connecting the Cables
You can connect up the cables required for printing to the printer. They all connect to the connector panel
on the back of the printer, which is shown below:
Before connecting any of the cables, make sure that both the printer and the computer are turned off.
For connection to a
host computer.
For connection to a
host computer.
Connects to peripheral units
such as cash drawers, etc.
Do not connect this to a
telephone.
For connection of the AC
adapter. Never unplug the
AC adapter while the printer
is on.
PERIPHERAL
DRIVE CONNECTOR
To Next Page
