1. Parts Identifications
INTERFACE CONNECTOR(USB)
INTERFACE CONNECTOR
PERIPHERAL
DRIVE CONNECTOR
POWER CONNECTOR
PRINTER COVER
CONTROL PANEL
COVER OPEN LEVER
POWER SWITCH
Open this cover to
load or replace paper.
Features LED indicators
to indicate printer status
and switches to operate
the printer.
Used to turn on/off
power to the printer.
Pull down this lever to
open the printer cover.
