KNOW YOUR TVS PHOENIX 125
KNOW YOUR TVS PHOENIX 125
LOCATION OF PARTS - HANDLE BAR
1. Choke lever
2. Horn switch
3. Turn signal lamp switch
4. Clutch lever
5. Pass by switch
6. Rear view mirror L
7. High / low beam switch
8. Digital speedometer
9. Ignition cum steering lock
10. Master cylinder front*
11. Rear view mirror R
12. Hazard switch
13. Front brake lever
14. Throttle grip
15. Head lamp switch
16. Electric starter switch
17. Fuel tank cap
-7-
12
13
14
15
16
17
6 7 8
10 11
9
1
2
3
4
5
* Applicable only for Disc version

TVS PHOENIX Specifications

General

Engine Capacity	124.8 cc
Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Transmission	4-Speed
Front Suspension	Telescopic
Rear Suspension	Hydraulic Shock Absorber
