TVS PHOENIX User Manual

MANUFACTURER : TVS MOTOR COMPANY LIMITED
P.B. No. 4, Harita, Hosur - 635 109, India.
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE
Type : Single cylinder, 4 stroke, air
cooled spark ignition engine
Cylinder bore : 57 mm
Stroke : 48.8 mm
Piston displacement : 124.53 cc
Compression ratio : 9.4 : 1.0
Carburettor : UCAL UCD 25
Air filter : Paper filter element
Lubrication system : Positive lubrication
Maximum power in kW : 8.1 (11 bhp) @ 7500 rpm
Maximum torque in Nm : 10.8 @ 5500 rpm
Maximum speed : Around 100 km / hr
Engine idling rpm : 1400 ± 100 rpm (under
warm condition)
Starting system : Electric starter / kick starter
TRANSMISSION
Clutch : Wet - Multi plate type
Transmission : 4 speed constant mesh
Gear shift pattern : All up heel-toe shift
Primary transmission : Spur gears
Secondary transmission : Chain and sprockets
GEAR RATIOS
I gear : 3.273
II gear : 1.765
III gear : 1.238
IV gear : 0.958
Primary reduction : 3.250
Final reduction : 3.214
-62-

TVS PHOENIX Specifications

General

Engine Capacity	124.8 cc
Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Transmission	4-Speed
Front Suspension	Telescopic
Rear Suspension	Hydraulic Shock Absorber
