KNOW YOUR TVS PHOENIX 125
LOCATION OF PARTS - VEHICLE FRONT AND REAR
FRONT
1. Turn signal lamp front L
2. Head lamp assembly
3. Crash guard
4. Position lamps
5. Turn signal lamp front R
REAR
1. Pillion handle
2. Tail lamp assembly
3. Turn signal lamp rear R
4. Reflex reflector
5. Turn signal lamp rear L
KNOW YOUR TVS PHOENIX 125
-10-
5
4
5
4
1
1
2
3
3
2
