KNOW YOUR TVS PHOENIX 125
LOCATION OF PARTS - VEHICLE RIGHT SIDE
1. Disc plate front*
2. Front wheel axle nut
3. Front caliper assembly*
4. Spark plug
5. Gauge oil level
6. Rear brake pedal
7. Kickstarter lever
8. Rider foot rest R
9. Pillion foot rest R
10. Muffler assembly
11. Rear brake adjuster
12. Rear shock absorber R
13. Cover frame R screw
KNOW YOUR TVS PHOENIX 125
-9-
1239
1011
12
13
* Applicable only for Disc version
45678
