TVS PHOENIX User Manual

MAINTENANCE
-32-
Item In free service After free service
Service 1st 2nd 3rd 4th 5th Remarks
Every Every
km 500-750 2500-3000 5000-6000 8500-9000 11500-12000
3000 km 6000 km
Period from the date of sale 1 month 3 months 6 months 9 months 12 months
All bulbs, horn and switches I I I I I I – Inspect for proper functioning
Head lamp beam I & A I & A I & A I & A I & A I & A –
Battery electrolyte level I & T I & T I & T I & T I & T I & T –
2
Specific gravity and voltage I I I I I I –
3
Brake effectiveness / play I & A I & A I & A I & A I & A I & A –
Brake cams – – C & L – C & L – C & L Lubricate using grease
Brake pad wear* I I I I I I – Replace if necessary
Brake fluid* I & T I & T I & T I & T I & T I & T – Replace every 21000 km
Brake hose* I I I I I I – Replace every three years
Master cylinder cups* – – – – – – – Replace every 21000 km
Wheel freeness I I I I I I –
Tyre pressure at cold condition I & S I & S I & S I & S I & S I & S –
Engine idling RPM I & S I & S I & S I & S I & S I & S –
4
Idling CO% I & S – – – – – –
Centre / side stand pivot L L L L L L – Lubricate using TRU4 oil
Kick starter pedal pivot L L L L L L – Lubricate using TRU4 oil
Swing arm bearings – – – – – – – Lubricate using grease
every two years
R - Replace; I - Inspect; T - Top up; C - Clean; A - Adjust; L - Lubricate; TI - Tighten; S - Set
1 2
Inspect for proper operation and adjust play. Lubricate ends using grease. Recharge if necessary
3
Lubricate brake pedal shaft every service using TRU4 oil
4
Idling CO% should be set with the help of exhaust gas analyser and tachometer only * Applicable only for Disc version
MAINTENANCE

TVS PHOENIX Specifications

General

Engine Capacity	124.8 cc
Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Transmission	4-Speed
Front Suspension	Telescopic
Rear Suspension	Hydraulic Shock Absorber
