Rebar Scanner A60+
14
During detection, press the RANGE key to switch the first
nominal range（ ）and the second nominal range（ ）. After
switching the nominal range, the probe must be self-calibrated by
means of pressing the ENTER key. Otherwise, detecting results are
wrong. When the direction is →，press the↓ key to change it into ↓.
At this time, horizontal rebar of grid pattern is detected. Press the
SAVE key to save the data（only the direction is↓）. Press the ENTER
key to self-calibrate probe. At this time, the probe must be placed in
the air and away from rebar and strong magnetic field. After wait on
the screen is missing, self-calibration is end. Then continue detection.
The difference between 1.0×1.0m & 2.0×2.0m and 0.5×0.5m
lies in that horizontal & longitudinal distances of probe relative to the
zero point are respectively ≤1.0m and ≤2.0m. Detection method is the
same.
No boundary scan is convenient for user to carry out a large area
scanning. It gets rid of the limitation of scanning boundary. At the
same time, the maximum scanning range is extended to 10m×10m.
For no boundary scan, the region shown on each screen is 2.0×2.0m.
When the distance is beyond this range, this system will switch
display region automatically. The difference between no boundary
scan and 0.5×0.5m lies in that horizontal & longitudinal distances of
probe relative to the zero point are ≤10m. Detection method is the
same.
During using no boundary scan, please follow strictly the
regulation that forward speed of trolley is not more than 20mm/s.
