Rebar Scanner A60+
15
Otherwise, missing rebar and display confusion will occur possibly. If
probable scanning range is known, scanning with boundary is
recommended because layout of rebar can be showed more visually.
3.2.5.2 Profile scan
Section plane scan is used for detection of multiple parallel rebar.
Interface of section plane scan is showed as figure 3-10. Through ↑
and ↓keys, according to horizontal length that requires being detected,
press the ENTER key to enter into the interface of detecting this
length.
Figure 3-10 interface of Profile scan
Interface of 0.5m section plane rebar scan is shown as figure 3-11.
Firstly, project information is set including Diameter of longitudinal
rebar (default is 16mm) and No. (The initial position is fixed as 4).
Press ← and →keys to move the cursor and press ↑ and ↓keys to
adjust the value of cursor position. Press the ESC key to return the
function selection interface. After above setting is end, press the
ENTER key to confirm the setting. Then probe is self-calibrated. At
this time, probe should be placed in the air and away from the strong
magnetic field interference. At the same time, wait！is showed on the
screen. After wait is missing, it indicates self-calibration of probe is
end. At this time, enter into detection status.
>>0.5m
1.0m
2.0m
