Max Level (No Input Pad)
AMP 26.1dBu
LINE 11.3dBu
INST. 2.8dBu
Max Level (With Input
Pad)
AMP 36.2dBu
LINE 20.8dBu
INST. 12.3dBu
Aux In
Connector 1/8” (3.5mm) TRS jack
Input Impedance 29kΩ
TO SPEAKER Output* 1/4″ Jack balanced (TS)
*Unprocessed, unbuffered, directly
connected to “From Amp”
DI Output*
XLR balanced
*Protected against +48V phantom
power
Max level: 10dBu
Output Impedance: 600Ω
DI Output*
1/4″ Jack balanced (TRS)
*Not Protected against +48V phantom
power
Max level: 10dBu
Output Impedance: 600Ω
Headphone Output
1/8“ (3.5mm) TRS jack
Max output power: 300mW under 100Ω
Output impedance: 33Ω
USB Connector USB-C 2.0
Memory Card 256Mb Micro-SD included Up to 32Gb cards supported
Digital Audio
AD/DA Converters Studio-grade 24-bit / 96kHz
Bandwidth (-1dB) 30Hz - 19kHz (-1dB)
Dynamic Range 101dB
Internal Processing 32-bit floating-point
Latency 2.2ms (Line Input to Line Output)
Power
Power Input Connector
Connector: 2.1mm x 5.5mm
Polarity: Center negative
Voltage: 12V DC
Current: 200mA
Power consumption: approx. 2W
Supplied Adapter
Connector: 2.1mm x 5.5mm
Polarity: Center negative
Voltage: 12V DC
Max Current:2000mA
Dimensions & Weight
Width x Depth x Height*
12.1cm x 10 cm x 6cm ( 4.8” 4“ x
2.4”)
*Including connectors and knobs
Weight 450g / 0.99 lbs
