TWO TREES TTS Pro - Page 3

0201
CONTENTS
Part list
Parameters
Assembly
Wiring
Adjustment
ReferenceE of Materials
Adjust the focus
Machine Introduction
Description of motherboard PCB
How to Start ?
Connect PC
GRBL introduction
Test before use
APP connection
After-sales affirmation
02
03
04
10
10
11
12
14
14
15
16
16
18
19
20
Tool Kit X1
Tracheal fittings X1
M5*10 X4
M3*8 X2
M3*6 X2 M3*20 X2
M5*20 X8 SD card X1 card reader X1
Fixed-length
column seat
M4*20 X2
M4*50 X3
USB Cable X1
PART LIST
Y-axis back profile X1
Y-axis right frame X1 Y-axis left frame X1 Y-axis front profile X1
Bellows X axis
Holder X1
Motherboard
and wires X1
Bellows Holder X1
X-axis beam X1
Tensioner module X1
Carriage and lifting
module X1
EN
Foot Pad X4
Foot Pad X4
12V4A
Power Adapter X1
5.5W Laser X1
TTS 55Pro
11mmFixed-length column
24V4A
Power Adapter X1
23mm Fixed-
length column
TTS 10Pro
10W Laser X1
